Tannoy · Legacy · Floorstander
Arden
Product description
The largest of the three 1970s cabinets Tannoy put back into production in 2017, rebuilt around a modern 380 mm Dual Concentric rather than the original HPD driver. Three distributed ports across the lower baffle load a 19 mm MDF cabinet with plywood bracing, and at 93 dB it is squarely valve-amplifier territory. Wide and shallow in the way seventies speakers were, which suits a wall it can sit against.
Units
| Type | Floorstander |
|---|---|
| HiFi ladder position | #31 of 473 floorstander |
| Power | Passive |
| Height | 910 mm |
| Width | 602 mm |
| Depth | 362 mm |
| Weight | 41 kg |
| Enclosure | bass-reflex-front |
| Drivers | 1× 33 mm tweeter (aluminium/magnesium alloy dome), 1× 380 mm woofer (paper pulp cone with single roll rubber surround) |
| Crossover frequency | 1100 Hz |
| Frequency response | 38–30000 Hz (±6 dB) |
| Sensitivity | 93 dB |
| Impedance | 8 Ω |
| Power handling | 150–600 W |
| Recommended amp | 20–300 W |
| Where to buy | Check availability ↗ |
| Manufacturer | web.archive.org ↗ |
| Product page | Open product page ↗ |
