Tannoy · Prestige · Bookshelf
Autograph MiniGR
Product description
The smallest Dual Concentric Tannoy makes: a 100 mm cone with a 19 mm titanium dome at its centre, in a 3.45-litre rear-ported cabinet with a triangular plan that breaks up internal standing waves. It is a scale model of the corner-horn Autograph in look rather than in principle, and it trades bass for coherence — 106 Hz at ±3 dB means a subwoofer or a small room, but the point-source imaging is the full-size article.
Units
| Type | Bookshelf |
|---|---|
| HiFi ladder position | #168 of 367 bookshelf |
| Power | Passive |
| Height | 356 mm |
| Width | 209 mm |
| Depth | 156 mm |
| Weight | 4.4 kg |
| Enclosure | bass-reflex-rear |
| Drivers | 1× 19 mm tweeter (titanium dome), 1× 100 mm mid-bass (paper pulp cone) |
| Crossover frequency | 2000 Hz |
| Frequency response | 106–20000 Hz (±3 dB) |
| Sensitivity | 85 dB |
| Impedance | 8 Ω |
| Power handling | 50–200 W |
