Tannoy · Legacy · Floorstander
Cheviot
Product description
The middle Legacy cabinet, a 300 mm Dual Concentric crossing to a 25 mm dome at 1.2 kHz through twin distributed ports. At 260 mm it is shallower than almost anything of its output, which is what the wide seventies baffle bought — the same 38 Hz reach as the larger Arden from a cabinet a third lighter. A gold control panel on the baffle sets treble energy and roll-off.
Units
| Type | Floorstander |
|---|---|
| HiFi ladder position | #15 of 473 floorstander |
| Power | Passive |
| Height | 860 mm |
| Width | 448 mm |
| Depth | 260 mm |
| Weight | 29 kg |
| Enclosure | bass-reflex-front |
| Drivers | 1× 25 mm tweeter (aluminium/magnesium alloy dome), 1× 300 mm woofer (paper pulp cone with twin roll impregnated fabric surround) |
| Crossover frequency | 1200 Hz |
| Frequency response | 38–30000 Hz (±6 dB) |
| Sensitivity | 91 dB |
| Impedance | 8 Ω |
| Power handling | 125–500 W |
| Recommended amp | 20–250 W |
