Neumann · KH Line · Studio monitor

KH 310 II

Product description
The successor to the KH 310 A, and the point at which Neumann's veteran three-way nearfield turns digital. The cabinet is unchanged in size and still sealed rather than ported, with the same horizontal layout — an 8.25-inch woofer beside a 3-inch soft-dome midrange and a 1-inch tweeter — but Class AB gives way to Class D, amplifier power rises from 390 W to 585 W, and a DSP engine now handles the crossover, linear-phase FIR correction and MA 1 room alignment. Maximum SPL climbs to 121.4 dB. Inputs are analogue XLR and AES3id on BNC, with the digital signal passed through to the next monitor. Still handed: you order a left or a right so the midrange and treble face the outside of the monitoring triangle. Sold individually.
Units
TypeStudio monitor
HiFi ladder position#8 of 86 studio monitor
PowerActive
Height253 mm
Width383 mm
Depth292 mm
Weight13 kg
Enclosuresealed
Drivers1× 25 mm tweeter, 1× 75 mm midrange (soft dome), 1× 210 mm woofer
Crossover frequency700 / 1700 Hz
Frequency response33–21000 Hz (±3 dB)
MAP (USD)$2,999 each
Amplification (per driver)tweeter 125 W (class D) · midrange 160 W (class D) · woofer 300 W (class D)
Total amp power585 W
Max SPL @ 1 m121.4 dB
Hi-res audio24 bit / 200 kHz
Wired inputsXLR balanced, AES/EBU (XLR), Ethernet
Streaming / wireless
Outputs
Room correctionCustom DSP / app
Primary + secondary pairNo
Wireless inter-speaker linkNo
Latency2.6 ms
Idle power26 W
Max consumption320 W
