Steinway Lyngdorf · Floorstander
Model B
Product description
The Model D's dipole idea folded into a cabinet half its height: six 305 mm woofers, three on the front and three on the back, mounted on an open aluminium frame with no box behind them, and the sides turned back to widen the baffle acoustically rather than visually. Quad-amplified by the A2 at 4 × 400 W, with the whole crossover computed in the amplifier, it holds 25 Hz and 115 dB from 140 kg.
Units
| Type | Floorstander |
|---|---|
| HiFi ladder position | #467 of 624 floorstander |
| Power | Passive |
| Height | 1240 mm |
| Width | 600 mm |
| Depth | 310 mm |
| Weight | 140 kg |
| Enclosure | Open baffle |
| Drivers | 1× tweeter (AMT), 1× 127 mm midrange (aluminium cone), 6× 305 mm woofer (glass-fibre honeycomb cone) |
| Frequency response | 25–22000 Hz (±3 dB) |
| Where to buy | Check availability ↗ |
| Manufacturer | steinwaylyngdorf.com ↗ |
| Product page | Open product page ↗ |
