Acoustic Energy · Floorstander
AE109²
Product description
A floorstander 165 mm wide — no wider than the AE100² standmount it comes from — running that speaker's 125 mm driver twice in a 2.5-way. The second cone only works the bottom, which is how a cabinet this slim gets to 41 Hz, and the enclosure is mass-loaded at the base to keep it still.
Units
| Type | Floorstander |
|---|---|
| HiFi ladder position | #21 of 580 floorstander |
| Power | Passive |
| Height | 860 mm |
| Width | 165 mm |
| Depth | 250 mm |
| Weight | 16 kg |
| Enclosure | Bass reflex, rear port |
| Drivers | 1× 25 mm tweeter (fabric dome), 2× 125 mm mid-bass (paper cone) |
| Crossover frequency | 275 / 2500 Hz |
| Frequency response | 41–26000 Hz |
| Sensitivity | 89 dB |
| Impedance | 6 Ω |
| Power handling | 175 W |
| Where to buy | Check availability ↗ |
| Manufacturer | acoustic-energy.co.uk ↗ |
| Product page | Open product page ↗ |
