Acoustic Energy · Bookshelf

AE2 40th Anniversary

Product description
A larger 40th-anniversary standmount with twin 125 mm ceramic-coated aluminium mid/bass drivers around a 29 mm aluminium-dome tweeter, in a heavily-braced RSC constrained-layer cabinet with triple front ports. A limited-run reference monitor reaching 35 Hz, hand-built in the UK.

Performance — where it sits in the catalog

BassTrebleSensitivityEasy loadCone area
Bass reachTreble reachSensitivityEasy loadCone area
AE2 40th Anniversary35 Hz45 kHz88 dB6 Ω252 cm²
Median45 Hz25 kHz87 dB6 Ω219 cm²
How to read this chart

Each axis spans the range the 470 bookshelves in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 385 passive bookshelves — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe.

Units
TypeBookshelf
HiFi ladder position#291 of 470 bookshelf
PowerPassive
Height385 mm
Width235 mm
Depth315 mm
Footprint740 cm²
Space taken28.5 L
Weight14.5 kg
EnclosureBass reflex, front port
Drivers1× 29 mm tweeter (anodised aluminium dome), 2× 125 mm mid-bass (aluminium cone)
Crossover frequency2200 Hz
Frequency response35–45000 Hz (±6 dB)
Sensitivity88 dB
Impedance6 Ω
Power handling200 W
MAP (USD)$2,999 / pair
Where to buyCheck availability ↗
Manufactureracoustic-energy.co.uk ↗
Product pageOpen product page ↗
