Ascilab · Bookshelf
S6B
$3,000 / pairCheck availability ↗
TrueScaleLine this speaker up next to another at its real-world size.TrueSpecsPut this speaker's full spec sheet beside up to three others.HiFi LadderJump to this speaker's spot on the HiFi Ladder, ranked by size.
Product description
AsciLab's flagship passive bookshelf: a 165 mm Purifi aluminium woofer flanked by two 8-inch Purifi passive radiators, with a 25 mm alumina-ceramic dome in an FEA-designed waveguide with phase plug. A 4th-order 1 kHz crossover and Klippel-NFS tuning yield a linear response, 41 Hz extension and a 102 dB maximum SPL from a sealed-plus-radiator cabinet.
Suggested TrueScale comparisons
Tap any speaker to see it beside this one at true, real-world scale.
Units
| Type | Bookshelf |
|---|---|
| HiFi ladder position | #247 of 362 bookshelf |
| Power | Passive |
| Height | 405 mm |
| Width | 220 mm |
| Depth | 300 mm |
| Weight | 13.5 kg |
| Enclosure | passive-radiator |
| Drivers | 1× 25 mm tweeter (alumina-ceramic dome), 1× 165 mm mid-bass (Purifi aluminium cone) |
| Crossover frequency | 1000 Hz |
| Frequency response | 41–25000 Hz (±3 dB) |
| Sensitivity | 82 dB |
| Impedance | 4 Ω |
| Power handling | undefined W |
| Recommended amp | undefined W |
| MAP (USD) | $3,000 / pair |
| Where to buy | Check availability ↗ |
| Manufacturer | ascilab.com ↗ |
| Product page | Open product page ↗ |
