Bowers & Wilkins · 800 · Bookshelf

805 D4

Product description
The stand-mount of the 800 Diamond range: a two-way with the diamond-dome Tweeter-on-Top and a single 6.5-inch Continuum bass/midrange in a compact Matrix-braced cabinet, pairing with the optional matching FS-805 D4 stand. Diamond-series resolution in a bookshelf footprint — for a smaller high-end room with quality amplification.

Performance — where it sits in the catalog

BassTrebleSensitivityEasy loadCone area
Bass reachTreble reachSensitivityEasy loadCone area
805 D442 Hz28 kHz88 dB8 Ω219 cm²
Median45 Hz25 kHz87 dB6 Ω219 cm²
How to read this chart

Each axis spans the range the 470 bookshelves in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 385 passive bookshelves — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe.

Units
TypeBookshelf
HiFi ladder position#369 of 470 bookshelf
PowerPassive
Height440 mm
Width228 mm
Depth373 mm
Footprint850 cm²
Space taken37.4 L
Weight15.55 kg
EnclosureBass reflex, front port
Drivers1× 25 mm tweeter (diamond dome), 1× 165 mm mid-bass (Continuum cone)
Frequency response42–28000 Hz (±3 dB)
Sensitivity88 dB
Impedance8 Ω (min 4.6 Ω)
Recommended amp50–120 W
MAP (USD)$8,000 / pair
Where to buyCheck availability ↗
Manufacturerbowerswilkins.com ↗
Product pageOpen product page ↗
