Elipson · Heritage XLS · Bookshelf

Heritage XLS 7

Product description
A retro-styled 2-way monitor in Elipson's Heritage line — a 6½-inch cellulose-pulp woofer and 22 mm silk-dome tweeter behind a black baffle in a walnut cabinet, with front-panel treble adjustment. A vintage JBL-L100-style bookshelf brought up to date, made by France's Elipson.

Performance — where it sits in the catalog

BassTrebleSensitivityEasy loadCone area
Bass reachTreble reachSensitivityEasy loadCone area
Heritage XLS 749 Hz25 kHz88 dB6 Ω218 cm²
Median45 Hz25 kHz87 dB6 Ω219 cm²
How to read this chart

Each axis spans the range the 470 bookshelves in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 385 passive bookshelves — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe.

Units
TypeBookshelf
HiFi ladder position#277 of 470 bookshelf
PowerPassive
Height380 mm
Width225 mm
Depth250 mm
Footprint563 cm²
Space taken21.4 L
Weight8.7 kg
EnclosureBass reflex, front port
Drivers1× 22 mm tweeter (silk dome), 1× 165 mm woofer (cellulose pulp cone)
Crossover frequency2400 Hz
Frequency response49–25000 Hz (±3 dB)
Sensitivity88 dB
Impedance6 Ω
MAP (USD)$869 / pair
Where to buyCheck availability ↗
Manufacturerelipson.com ↗
Product pageOpen product page ↗
