Elipson · Planet · Bookshelf

Planet M

Product description
The compact spherical 2-way of Elipson's iconic Planet line — a coaxial 4-inch paper mid/bass with a 25 mm silk-dome tweeter at its centre, sealed in a 15 cm glossy sphere that all but eliminates cabinet diffraction. A design-object satellite for desktop, shelf or surround duty, made by France's Elipson.

Performance — where it sits in the catalog

BassTrebleSensitivityEasy loadCone area
Bass reachTreble reachSensitivityEasy loadCone area
Planet M90 Hz22 kHz88 dB8 Ω83 cm²
Median45 Hz25 kHz87 dB6 Ω219 cm²
How to read this chart

Each axis spans the range the 470 bookshelves in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 385 passive bookshelves — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe.

Units
TypeBookshelf
HiFi ladder position#3 of 470 bookshelf
PowerPassive
Height158 mm
Width150 mm
Depth150 mm
Footprint225 cm²
Space taken3.6 L
Weight1.65 kg
EnclosureSealed
Drivers1× 25 mm tweeter (silk dome), 1× 100 mm mid-bass (paper cone)
Frequency response90–22000 Hz
Sensitivity88 dB
Impedance8 Ω
Power handling80 W
MAP (USD)$499 / pair
Where to buyCheck availability ↗
Manufacturerelipson.com ↗
Product pageOpen product page ↗
