Genelec · SAM · Studio monitor
1236A
Product description
The largest monitor Genelec makes: two 18-inch woofers reaching 17.5 Hz at −6 dB, flat to ±2 dB from 21 Hz, out of a 182 kg cabinet 1.18 m tall. Same 3050 W and ≥130 dB as the 1235A, spent on an octave of extra bottom end rather than more level — at this size the point is reproducing what a dubbing stage or a scoring room actually contains, not playing louder. SAM with GLM AutoCal. Sold individually. Made in Iisalmi, Finland.
Units
| Type | Studio monitor |
|---|---|
| HiFi ladder position | #101 of 111 studio monitor |
| Power | Active |
| Height | 1180 mm |
| Width | 960 mm |
| Depth | 650 mm |
| Weight | 182 kg |
| Enclosure | Bass reflex, rear port |
| Drivers | 1× 25 mm tweeter (compression driver in a DCW waveguide), 2× 125 mm midrange (cone), 2× 458 mm woofer (cone) |
| Frequency response | 21–20000 Hz (±2 dB) |
| Amplification (per driver) | tweeter 250 W (class D) · midrange 400 W (class D) · woofer 1000 W (class D) |
| Total amp power | 3050 W |
| Max SPL @ 1 m | 130 dB |
| Hi-res audio | — |
| Wired inputs | XLR balanced, AES/EBU (XLR), Ethernet |
| Streaming / wireless | — |
| Outputs | — |
| Room correction | Custom DSP / app |
| Primary + secondary pair | No |
| Wireless inter-speaker link | No |
| Latency | — |
| Idle power | — |
| Max consumption | — |
| Where to buy | Check availability ↗ |
| Manufacturer | genelec.com ↗ |
| Product page | Open product page ↗ |
