Genelec · 8300 Series · Studio monitor

8320A

Product description
The compact SAM monitor of Genelec's 8300 series — the DSP-equipped sibling of the 8020, a 4-inch woofer and 19 mm metal-dome tweeter in a rounded die-cast aluminium cabinet, bi-amped with 2 × 50 W of Class D. GLM network calibration tunes its onboard DSP to the room; a tiny, self-calibrating nearfield, made in Finland.

Performance — where it sits in the catalog

BassTrebleCone area
Bass reachTreble reachCone area
8320A55 Hz23 kHz89 cm²
Median39 Hz24 kHz332 cm²
How to read this chart

Each axis spans the range the 114 studio monitors in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 96 active studio monitors — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe. Not shown: Sensitivity, Easy load — the maker publishes no figure. Active speakers quote no sensitivity and no impedance, because with the amplifier inside both describe the electronics rather than the cabinet.

Units
TypeStudio monitor
HiFi ladder position#7 of 114 studio monitor
PowerActive
Height242 mm
Width151 mm
Depth142 mm
Footprint214 cm²
Space taken5.2 L
Weight3.2 kg
EnclosureBass reflex, rear port
Drivers1× 19 mm tweeter (metal dome), 1× 105 mm mid-bass (cone)
Crossover frequency3000 Hz
Frequency response55–23000 Hz (±1.5 dB)
MAP (USD)$850 each
Amplification (per driver)tweeter 50 W (class D) · mid-bass 50 W (class D)
Total amp power100 W
Max SPL @ 1 m100 dB
Hi-res audio—
Wired inputsXLR balanced, Ethernet
Streaming / wireless—
Outputs—
Room correctionCustom DSP / app
Primary + secondary pair—
Wireless inter-speaker link—
Latency—
Idle power—
Max consumption—
