Genelec · Studio monitor

8380A

Product description
A three-way SAM main monitor — a huge 15-inch woofer under a coaxial 130 mm midrange and 25 mm tweeter, 950 W of amplification to 122 dB, in a 54 kg reflex-loaded cabinet reaching 29 Hz. Genelec's GLM room calibration tunes it for large control rooms; a full-scale point-source main monitor, made in Finland.

Performance — where it sits in the catalog

BassTrebleCone area
Bass reachTreble reachCone area
8380A29 Hz43 kHz1272 cm²
Median39 Hz24 kHz332 cm²
How to read this chart

Each axis spans the range the 114 studio monitors in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 96 active studio monitors — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe. Not shown: Sensitivity, Easy load — the maker publishes no figure. Active speakers quote no sensitivity and no impedance, because with the amplifier inside both describe the electronics rather than the cabinet.

Units
TypeStudio monitor
HiFi ladder position#93 of 114 studio monitor
PowerActive
Height810 mm
Width480 mm
Depth420 mm
Footprint2016 cm²
Space taken163.3 L
Weight54 kg
EnclosureBass reflex, rear port
Drivers1× 25 mm tweeter (metal dome), 1× 130 mm midrange (cone), 1× 380 mm woofer (cone)
Crossover frequency470 / 2500 Hz
Frequency response29–43000 Hz (±1.5 dB)
MAP (USD)$11,075 each
Amplification (per driver)tweeter 200 W (class AB) · midrange 250 W (class D) · woofer 500 W (class D)
Total amp power950 W
Max SPL @ 1 m122 dB
Hi-res audio—
Wired inputsXLR balanced, AES/EBU (XLR)
Streaming / wireless—
Outputs—
Room correctionCustom DSP / app
Primary + secondary pair—
Wireless inter-speaker link—
Latency—
Idle power—
Max consumption—
