Kudos · Titan · Bookshelf

Titan 505

Product description
The stand-mount of Kudos's flagship Titan range — a 2-way with the SEAS-Kudos K3 29 mm tweeter over an isobaric pair of 180 mm paper mid/bass drivers, one hidden inside the cabinet. The isobaric loading gives deep, controlled bass from a compact box, with an optional active-crossover mode. Hand-built in County Durham, England.

Performance — where it sits in the catalog

BassTrebleSensitivityEasy loadCone area
Bass reachTreble reachSensitivityEasy loadCone area
Titan 50540 Hz30 kHz87 dB6 Ω516 cm²
Median45 Hz25 kHz87 dB6 Ω219 cm²
How to read this chart

Each axis spans the range the 470 bookshelves in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 385 passive bookshelves — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe.

Units
TypeBookshelf
HiFi ladder position#377 of 470 bookshelf
PowerPassive
Height450 mm
Width256 mm
Depth320 mm
Footprint819 cm²
Space taken36.9 L
Weight18 kg
EnclosureBass reflex, down-firing port
Drivers1× 29 mm tweeter (fabric dome), 2× 180 mm mid-bass (coated paper cone)
Frequency response40–30000 Hz
Sensitivity87 dB
Impedance6 Ω
Recommended amp25–250 W
MAP (USD)$12,300 / pair
Where to buyCheck availability ↗
Manufacturerkudosaudio.com ↗
Product pageOpen product page ↗
