Magnat · Monitor Reference · Floorstander

Monitor Reference 5A

Product description
The Monitor Reference 2A's electronics and connection list moved into a floorstander: 2 × 60 W of Class D in the right-hand cabinet, driving itself and a passive twin. The layout is 2.5-way — two 170 mm coated-paper cones under a 25 mm dome, the lower one rolling off early to reinforce the bass rather than duplicate the midrange — which takes the bottom end to 28 Hz from a tower only 205 mm wide. Rear Airflex port, crossover at 3.2 kHz. HDMI ARC, optical, Bluetooth 5.0 aptX, a 3.5 mm jack and an RCA pair with a switchable MM phono stage, all on the back of the active speaker. Matt-black baffle, black textured veneer.
Units
TypeFloorstander
HiFi ladder position#43 of 624 floorstander
PowerActive
Height908 mm
Width205 mm
Depth282 mm
Weight14.7 kg
EnclosureBass reflex, rear port
Drivers1× 25 mm tweeter (dome), 1× 170 mm mid-bass (coated paper cone), 1× 170 mm woofer (coated paper cone)
Crossover frequency3200 Hz
Frequency response28–40000 Hz
MAP (USD)$799 / pair
Amplification (per driver)—
Total amp power120 W
Max SPL @ 1 m—
Hi-res audio—
Wired inputsRCA Phono, RCA, Optical (Toslink), HDMI ARC
Streaming / wirelessBluetooth
Outputs—
Room correction—
Primary + secondary pairYes
Wireless inter-speaker linkNo
Latency—
Idle power—
Max consumption—
