Magnat · Monitor S · Floorstander
Monitor S80 ATM
$349 eachCheck availability ↗
Product description
The S70's smaller sibling with a Dolby Atmos module built into the top: a 115 mm coaxial driver firing at the ceiling, on its own pair of terminals and its own 40 W amplifier channel, so the height layer comes from the same cabinet as the fronts rather than a box balanced on top. The main speaker below is a 2.5-way — two 165 mm cones under a 28 mm fabric dome, crossed at 500 Hz and 3 kHz, down to 26 Hz. Rear Airflex port, magnetic fabric grille, rubber feet. Black or walnut. Priced per speaker.
Units
| Type | Floorstander |
|---|---|
| HiFi ladder position | #15 of 494 floorstander |
| Power | Passive |
| Height | 860 mm |
| Width | 215 mm |
| Depth | 270 mm |
| Weight | 13.4 kg |
| Enclosure | bass-reflex-rear |
| Drivers | 1× 28 mm tweeter (fabric dome), 2× 165 mm mid-bass, 1× 115 mm midrange (coaxial) |
| Crossover frequency | 500 / 3000 Hz |
| Frequency response | 26–38000 Hz |
| Sensitivity | 90 dB |
| Impedance | 4 Ω |
| Power handling | 300 W |
| Recommended amp | 30–300 W |
| MAP (USD) | $349 each |
| Where to buy | Check availability ↗ |
| Manufacturer | magnat.com ↗ |
| Product page | Open product page ↗ |
