MartinLogan · Masterpiece · Floorstander

Expression ESL 13A

Product description
A hybrid electrostatic in MartinLogan's flagship Masterpiece line — the curved XStat panel handles midrange and treble while twin 254 mm aluminium woofers run active, driven by two internal 300 W Class-D amps with Anthem Room Correction. The powered, room-corrected bass solves the usual electrostatic weakness; it still needs an external amp for the panel.

Performance — where it sits in the catalog

BassTrebleSensitivityEasy load
Bass reachTreble reachSensitivityEasy load
Expression ESL 13A24 Hz23 kHz91 dB4 Ω
Median32 Hz30 kHz90 dB6 Ω
How to read this chart

Each axis spans the range the 648 floorstanders in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 600 passive floorstanders — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe. Not shown: Cone area — the maker publishes no figure.

Units
TypeFloorstander
HiFi ladder position#602 of 648 floorstander
PowerHybrid (active bass)
Height1561 mm
Width339 mm
Depth699 mm
Footprint2405 cm²
Space taken375.4 L
Weight46.8 kg
EnclosureSealed
Drivers1× midrange (electrostatic (XStat CLS)), 2× 254 mm woofer (aluminium cone)
Crossover frequency300 Hz
Frequency response24–23000 Hz (±3 dB)
Sensitivity91 dB
Impedance4 Ω (min 0.7 Ω)
Recommended amp20–600 W
MAP (USD)$14,995 / pair
