MartinLogan · Motion · Floorstander

Motion F10

Product description
A three-way Motion floorstander — the Gen2 Obsidian Folded Motion AMT tweeter with a 140 mm woven-fibreglass midrange and twin 140 mm aluminium woofers, down-ported. The entry Motion tower: AMT treble and full-range bass at 92 dB sensitivity for a medium room.

Performance — where it sits in the catalog

BassTrebleSensitivityEasy load
Bass reachTreble reachSensitivityEasy load
Motion F1038 Hz25 kHz92 dB4 Ω
Median32 Hz30 kHz90 dB6 Ω
How to read this chart

Each axis spans the range the 648 floorstanders in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 600 passive floorstanders — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe. Not shown: Cone area — the maker publishes no figure.

Units
TypeFloorstander
HiFi ladder position#93 of 648 floorstander
PowerPassive
Height971 mm
Width286 mm
Depth337 mm
Footprint964 cm²
Space taken93.6 L
Weight22.9 kg
EnclosureBass reflex, down-firing port
Drivers1× tweeter (Folded Motion (AMT)), 1× 140 mm midrange (woven-fibreglass cone), 2× 140 mm woofer (aluminium cone)
Crossover frequency280 / 3000 Hz
Frequency response38–25000 Hz (±3 dB)
Sensitivity92 dB
Impedance4 Ω
Recommended amp20–250 W
MAP (USD)$2,500 / pair
Where to buyCheck availability ↗
Manufacturermartinlogan.com ↗
Product pageOpen product page ↗
