MartinLogan · Masterpiece · Floorstander

Neolith

Product description
MartinLogan's statement hybrid electrostatic — a huge curved XStat panel paired with a 381 mm aluminium woofer and a 305 mm carbon-fibre driver in a rear-ported cabinet nearly two metres tall. Its impedance falls to well under an ohm at the top of the range, so it demands a genuinely current-capable amplifier and a large dedicated room.

Performance — where it sits in the catalog

BassTrebleSensitivityEasy load
Bass reachTreble reachSensitivityEasy load
Neolith23 Hz22 kHz90 dB4 Ω
Median32 Hz30 kHz90 dB6 Ω
How to read this chart

Each axis spans the range the 648 floorstanders in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 600 passive floorstanders — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe. Not shown: Cone area — the maker publishes no figure.

Units
TypeFloorstander
HiFi ladder position#632 of 648 floorstander
PowerPassive
Height1899 mm
Width769 mm
Depth870 mm
Footprint6020 cm²
Space taken1143.3 L
Weight175 kg
EnclosureBass reflex, rear port
Drivers1× midrange (electrostatic (XStat CLS)), 1× 381 mm woofer (aluminium cone), 1× 305 mm woofer (carbon-fibre cone)
Crossover frequency60 / 250 / 400 Hz
Frequency response23–22000 Hz (±3 dB)
Sensitivity90 dB
Impedance4 Ω (min 0.43 Ω)
Recommended amp20–1300 W
MAP (USD)$79,995 / pair
Where to buyCheck availability ↗
Manufacturermartinlogan.com ↗
Product pageOpen product page ↗
