MartinLogan · Masterpiece · Floorstander

Renaissance ESL 15A

Product description
A large Masterpiece hybrid electrostatic — the curved XStat panel over twin 305 mm aluminium woofers powered by two internal 500 W Class-D amps with Anthem Room Correction. Bigger panel and bigger powered woofers than the Expression 13A, reaching 22 Hz for a large dedicated room; an external amp still drives the panel.

Performance — where it sits in the catalog

BassTrebleSensitivityEasy load
Bass reachTreble reachSensitivityEasy load
Renaissance ESL 15A22 Hz21 kHz92 dB4 Ω
Median32 Hz30 kHz90 dB6 Ω
How to read this chart

Each axis spans the range the 648 floorstanders in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 600 passive floorstanders — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe. Not shown: Cone area — the maker publishes no figure.

Units
TypeFloorstander
HiFi ladder position#628 of 648 floorstander
PowerHybrid (active bass)
Height1773 mm
Width400 mm
Depth633 mm
Footprint2526 cm²
Space taken447.8 L
Weight63.5 kg
EnclosureSealed
Drivers1× midrange (electrostatic (XStat CLS)), 2× 305 mm woofer (aluminium cone)
Crossover frequency300 Hz
Frequency response22–21000 Hz (±3 dB)
Sensitivity92 dB
Impedance4 Ω (min 0.5 Ω)
Recommended amp20–700 W
MAP (USD)$24,995 / pair
Where to buyCheck availability ↗
Manufacturermartinlogan.com ↗
Product pageOpen product page ↗
