Mission · 700 · Bookshelf

770

Product description
The flagship of Mission's heritage 700 range — a large 200 mm mineral-loaded polypropylene mid-bass with the 28 mm woven-textile tweeter below it, front-ported. A faithful revival of the original 770 studio monitor, its big cone and 88 dB sensitivity giving genuine scale from a standmount in a medium room.

Performance — where it sits in the catalog

BassTrebleSensitivityEasy loadCone area
Bass reachTreble reachSensitivityEasy loadCone area
77042 Hz20 kHz88 dB8 Ω320 cm²
Median45 Hz25 kHz87 dB6 Ω219 cm²
How to read this chart

Each axis spans the range the 470 bookshelves in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 385 passive bookshelves — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe.

Units
TypeBookshelf
HiFi ladder position#434 of 470 bookshelf
PowerPassive
Height590 mm
Width300 mm
Depth322 mm
Footprint966 cm²
Space taken57 L
Weight19.2 kg
EnclosureBass reflex, front port
Drivers1× 200 mm mid-bass (mineral-loaded polypropylene), 1× 28 mm tweeter (woven textile soft dome)
Crossover frequency2900 Hz
Frequency response42–20000 Hz (±3 dB)
Sensitivity88 dB
Impedance8 Ω (min 6 Ω)
Recommended amp25–200 W
MAP (USD)$5,000 / pair
Where to buyCheck availability ↗
Manufacturermission.co.uk ↗
Product pageOpen product page ↗
