Moondrop · Bookshelf

M4P MTM

Product description
Moondrop's first loudspeaker, and the measurement-first ethos of its in-ear monitors scaled to the desktop. The M4P-MTM is a passive two-way in a vertical MTM (D'Appolito) layout — a 1-inch aluminium-magnesium dome tweeter flanked by two 4-inch carbon-cone woofers — for flat, low-distortion near-field sound with controlled vertical dispersion. It needs an external amplifier and has dual binding posts for bi-wiring or an active crossover.

Performance — where it sits in the catalog

BassTrebleSensitivityEasy loadCone area
Bass reachTreble reachSensitivityEasy loadCone area
M4P MTM60 Hz30 kHz85 dB4 Ω162 cm²
Median45 Hz25 kHz87 dB6 Ω219 cm²
How to read this chart

Each axis spans the range the 485 bookshelves in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 387 passive bookshelves — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe.

Units
TypeBookshelf
HiFi ladder position#291 of 485 bookshelf
PowerPassive
Height380 mm
Width155 mm
Depth185 mm
Footprint287 cm²
Space taken10.9 L
Weight6.2 kg
EnclosureBass reflex, rear port
Drivers1× 25 mm tweeter (aluminium-magnesium alloy dome), 2× 100 mm mid-bass (carbon fibre cone)
Crossover frequency1800 Hz
Frequency response60–30000 Hz (±3 dB)
Sensitivity85 dB
Impedance4 Ω
Power handling150 W
Recommended amp150 W
MAP (USD)$400 each
Where to buyCheck availability ↗
Manufacturermoondroplab.com ↗
Product pageOpen product page ↗
