Neat Acoustics · Iota · Bookshelf

Iota II

Product description
Thirteen centimetres tall and 2.6 litres inside, with a 50 mm planar magnetic tweeter standing vertically beside the 100 mm cone rather than above it — the layout that lets the cabinet be this short. Bob Surgeoner calls it the design he is proudest of. Neat quotes 33 Hz from it, which is the whole point of the thing.

Performance — where it sits in the catalog

BassTrebleEasy loadCone area
Bass reachTreble reachEasy loadCone area
Iota33 Hz22 kHz6 Ω98 cm²
Median45 Hz25 kHz6 Ω219 cm²
How to read this chart

Each axis spans the range the 452 bookshelves in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 380 passive bookshelves — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe. Not shown: Sensitivity — the maker publishes no figure.

Units
TypeBookshelf
HiFi ladder position#1 of 452 bookshelf
PowerPassive
Height130 mm
Width200 mm
Depth165 mm
Footprint330 cm²
Space taken4.3 L
Weight—
EnclosureBass reflex
Drivers1× 100 mm mid-bass (polypropylene cone), 1× 50 mm tweeter (planar magnetic)
Frequency response33–22000 Hz
Impedance6 Ω
Recommended amp25–100 W
