Perlisten · R · Bookshelf

R4b

Product description
A sealed three-way bookshelf carrying Perlisten's silk-dome DPC-Array — a 26 mm tweeter flanked by two matching domes — over a single 165 mm hybrid-pulp woofer in an acoustic-suspension cabinet. THX Ultra certified, a compact Reference monitor for a small room, sub-friendly by design.

Performance — where it sits in the catalog

BassTrebleSensitivityEasy loadCone area
Bass reachTreble reachSensitivityEasy loadCone area
R4b45 Hz32 kHz84.6 dB4 Ω230 cm²
Median45 Hz25 kHz87 dB6 Ω219 cm²
How to read this chart

Each axis spans the range the 452 bookshelves in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 380 passive bookshelves — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe.

Units
TypeBookshelf
HiFi ladder position#274 of 452 bookshelf
PowerPassive
Height382 mm
Width230 mm
Depth236 mm
Footprint543 cm²
Space taken20.7 L
Weight9.5 kg
EnclosureSealed
Drivers1× 26 mm tweeter (silk dome), 2× 26 mm midrange (silk dome), 1× 165 mm woofer (hybrid pulp-fibre cone)
Frequency response45–32000 Hz (±10 dB)
Sensitivity84.6 dB
Impedance4 Ω (min 3.8 Ω)
Recommended amp50–200 W
MAP (USD)$5,390 / pair
Where to buyCheck availability ↗
Manufacturerperlistenaudio.com ↗
Product pageOpen product page ↗
