Piega · Coax · Bookshelf

Coax 411

Product description
A compact stand-mount in an extruded seamless-aluminium cabinet, built around Piega's C112+ coaxial ribbon — a single element handling midrange and treble to 50 kHz — over a 160 mm UHQD aluminium woofer. Swiss-made, sealed, and unusually resolving for its size.

Performance — where it sits in the catalog

BassTrebleSensitivityEasy load
Bass reachTreble reachSensitivityEasy load
Coax 41135 Hz50 kHz90 dB4 Ω
Median45 Hz25 kHz87 dB6 Ω
How to read this chart

Each axis spans the range the 470 bookshelves in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 385 passive bookshelves — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe. Not shown: Cone area — the maker publishes no figure.

Units
TypeBookshelf
HiFi ladder position#378 of 470 bookshelf
PowerPassive
Height450 mm
Width210 mm
Depth310 mm
Footprint651 cm²
Space taken29.3 L
Weight25 kg
EnclosureSealed
Drivers1× tweeter (coaxial ribbon), 1× 160 mm woofer (UHQD aluminium cone)
Frequency response35–50000 Hz
Sensitivity90 dB
Impedance4 Ω
Recommended amp20–200 W
MAP (USD)$11,995 / pair
Where to buyCheck availability ↗
Manufacturerpiega.ch ↗
Product pageOpen product page ↗
