Piega · Coax · Floorstander

Coax 611

Product description
A slim 3-way floorstander in Piega's extruded-aluminium cabinet: the C112+ coaxial ribbon over twin 160 mm UHQD woofers, bass-loaded by three passive radiators for extension from a narrow footprint. Swiss-made, reaching 32 Hz to 50 kHz.

Performance — where it sits in the catalog

BassTrebleSensitivityEasy load
Bass reachTreble reachSensitivityEasy load
Coax 61132 Hz50 kHz90 dB4 Ω
Median32 Hz30 kHz90 dB6 Ω
How to read this chart

Each axis spans the range the 648 floorstanders in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 600 passive floorstanders — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe. Not shown: Cone area — the maker publishes no figure.

Units
TypeFloorstander
HiFi ladder position#423 of 648 floorstander
PowerPassive
Height1170 mm
Width210 mm
Depth310 mm
Footprint651 cm²
Space taken76.2 L
Weight45 kg
EnclosurePassive radiator
Drivers1× tweeter (coaxial ribbon), 2× 160 mm woofer (UHQD aluminium cone)
Frequency response32–50000 Hz
Sensitivity90 dB
Impedance4 Ω
Recommended amp20–250 W
MAP (USD)$21,995 / pair
Where to buyCheck availability ↗
Manufacturerpiega.ch ↗
Product pageOpen product page ↗
