Piega · Coax · Floorstander

Coax 811

Product description
The flagship of Piega's Coax range — a large 3-way floorstander with the bigger C212+ coaxial ribbon over twin 220 mm UHQD woofers and two 220 mm passive radiators, in a seamless extruded-aluminium cabinet. Reaches 22 Hz at 92 dB. Swiss-made.

Performance — where it sits in the catalog

BassTrebleSensitivityEasy load
Bass reachTreble reachSensitivityEasy load
Coax 81122 Hz50 kHz92 dB4 Ω
Median32 Hz30 kHz90 dB6 Ω
How to read this chart

Each axis spans the range the 648 floorstanders in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 600 passive floorstanders — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe. Not shown: Cone area — the maker publishes no figure.

Units
TypeFloorstander
HiFi ladder position#486 of 648 floorstander
PowerPassive
Height1240 mm
Width290 mm
Depth420 mm
Footprint1218 cm²
Space taken151 L
Weight63 kg
EnclosurePassive radiator
Drivers1× tweeter (coaxial ribbon), 2× 220 mm woofer (UHQD aluminium cone)
Frequency response22–50000 Hz
Sensitivity92 dB
Impedance4 Ω
Recommended amp20–250 W
MAP (USD)$39,995 / pair
Where to buyCheck availability ↗
Manufacturerpiega.ch ↗
Product pageOpen product page ↗
