Piega · Master Line Source · Floorstander

Master Line Source 3

Product description
A dipole line-source floorstander with four vertically stacked ribbon drivers radiating cylindrically along a line, over twin 180 mm UHQD woofers and passive radiators, with rear acoustic lenses for flexible placement. One of Piega's Master statements, Swiss-made.

Performance — where it sits in the catalog

BassTrebleSensitivityEasy load
Bass reachTreble reachSensitivityEasy load
Master Line Source 328 Hz50 kHz92 dB4 Ω
Median32 Hz30 kHz90 dB6 Ω
How to read this chart

Each axis spans the range the 648 floorstanders in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 600 passive floorstanders — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe. Not shown: Cone area — the maker publishes no figure.

Units
TypeFloorstander
HiFi ladder position#612 of 648 floorstander
PowerPassive
Height1650 mm
Width230 mm
Depth330 mm
Footprint1158 cm²
Space taken191.1 L
Weight65 kg
EnclosurePassive radiator
Drivers4× tweeter (ribbon), 2× 180 mm woofer (UHQD aluminium cone)
Frequency response28–50000 Hz
Sensitivity92 dB
Impedance4 Ω
Recommended amp20–500 W
MAP (USD)$50,000 / pair
Where to buyCheck availability ↗
Manufacturerpiega.ch ↗
Product pageOpen product page ↗
