PMC · Fact · Floorstander
Fenestria
TrueScaleLine this speaker up next to another at its real-world size.TrueSpecsPut this speaker's full spec sheet beside up to three others.HiFi LadderJump to this speaker's spot on the HiFi Ladder, ranked by size.
Product description
PMC's flagship: a 3-way ATL tower with four 165 mm transverse-weave carbon-fibre bass drivers, a 75 mm nest-mounted soft-dome midrange and a 19.5 mm SONOMEX tweeter, on twin 2.4 m transmission lines. The central driver 'nest' floats between two mass-loaded wings to isolate resonance. 23 Hz–25 kHz, 86 dB, 4-ohm.
Suggested TrueScale comparisons
Tap any speaker to see it beside this one at true, real-world scale.
Units
| Type | Floorstander |
|---|---|
| HiFi ladder position | #331 of 337 floorstander |
| Power | Passive |
| Height | 1700 mm |
| Width | 370 mm |
| Depth | 623 mm |
| Weight | 80 kg |
| Enclosure | transmission-line |
| Drivers | 1× 19.5 mm tweeter (SONOMEX soft dome), 1× 75 mm midrange (soft dome), 4× 165 mm woofer (carbon-fibre cone) |
| Crossover frequency | 380 / 3800 Hz |
| Frequency response | 23–25000 Hz |
| Sensitivity | 86 dB |
| Impedance | 4 Ω |
| Recommended amp | 30–1000 W |
| MAP (USD) | $65,000 / pair |
| Where to buy | Check availability ↗ |
| Manufacturer | pmc-speakers.com ↗ |
| Product page | Open product page ↗ |
