Revel · Performa4 · Floorstander

F346

Product description
A three-way Performa4 floorstander developed through Harman's measurement-driven research — a DCC tweeter, 165 mm ceramic-composite midrange and three 165 mm woofers. The larger woofers take it to 30 Hz, making it the Performa4 tower for a medium-to-large room.

Performance — where it sits in the catalog

BassTrebleSensitivityEasy loadCone area
Bass reachTreble reachSensitivityEasy loadCone area
F34630 Hz40 kHz88 dB6 Ω860 cm²
Median32 Hz30 kHz90 dB6 Ω654 cm²
How to read this chart

Each axis spans the range the 648 floorstanders in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 600 passive floorstanders — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe.

Units
TypeFloorstander
HiFi ladder position#357 of 648 floorstander
PowerPassive
Height1127 mm
Width357 mm
Depth414 mm
Footprint1478 cm²
Space taken166.6 L
Weight39.7 kg
EnclosureBass reflex, rear port
Drivers3× 165 mm woofer (Micro Ceramic Composite (MCC) cone), 1× 165 mm midrange (Deep Ceramic Composite (DCC) cone), 1× 25 mm tweeter (ceramic composite (DCC) dome)
Frequency response30–40000 Hz (±6 dB)
Sensitivity88 dB
Impedance6 Ω
Recommended amp20–250 W
MAP (USD)$6,999 / pair
Where to buyCheck availability ↗
Manufacturerrevelspeakers.com ↗
Product pageOpen product page ↗
