Revel · Performa3 · Bookshelf

M105

Product description
The smallest Performa3, and the one that drops the midrange: a single 133 mm aluminium cone crossed straight to the waveguide tweeter at 2.3 kHz. Seven kilos and 36 cm tall, rear-ported, reaching 60 Hz at −3 dB — the entry point to Revel's measured-accuracy house sound.

Performance — where it sits in the catalog

BassTrebleSensitivityEasy loadCone area
Bass reachTreble reachSensitivityEasy loadCone area
M10560 Hz20 kHz86 dB8 Ω144 cm²
Median45 Hz25 kHz87 dB6 Ω219 cm²
How to read this chart

Each axis spans the range the 470 bookshelves in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 385 passive bookshelves — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe.

Units
TypeBookshelf
HiFi ladder position#223 of 470 bookshelf
PowerPassive
Height356 mm
Width200 mm
Depth248 mm
Footprint496 cm²
Space taken17.7 L
Weight7 kg
EnclosureBass reflex, rear port
Drivers1× 133 mm mid-bass (aluminium cone), 1× 25 mm tweeter (aluminium dome (acoustic lens waveguide))
Crossover frequency2300 Hz
Frequency response60–20000 Hz (±3 dB)
Sensitivity86 dB
Impedance8 Ω
Recommended amp50–120 W
MAP (USD)$1,500 / pair
Where to buyCheck availability ↗
Manufacturerrevelspeakers.com ↗
Product pageOpen product page ↗
