Revel · Performa4 · Bookshelf

M146

Product description
A two-way stand-mount of Revel's Performa4 line, developed through Harman's measurement-driven research. Its DCC ceramic-composite tweeter and larger 165 mm mid-bass extend low end to 43 Hz — the fuller-bodied Performa4 bookshelf for a small-to-mid room, on stands.

Performance — where it sits in the catalog

BassTrebleSensitivityEasy loadCone area
Bass reachTreble reachSensitivityEasy loadCone area
M14643 Hz40 kHz85.5 dB6 Ω219 cm²
Median45 Hz25 kHz87 dB6 Ω219 cm²
How to read this chart

Each axis spans the range the 470 bookshelves in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 385 passive bookshelves — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe.

Units
TypeBookshelf
HiFi ladder position#231 of 470 bookshelf
PowerPassive
Height359 mm
Width246 mm
Depth323 mm
Footprint733 cm²
Space taken26.3 L
Weight11 kg
EnclosureBass reflex, rear port
Drivers1× 165 mm mid-bass (Micro Ceramic Composite (MCC) cone), 1× 25 mm tweeter (ceramic composite (DCC) dome)
Frequency response43–40000 Hz (±6 dB)
Sensitivity85.5 dB
Impedance6 Ω
Recommended amp15–200 W
MAP (USD)$2,999 / pair
Where to buyCheck availability ↗
Manufacturerrevelspeakers.com ↗
Product pageOpen product page ↗
