Sigberg Audio · Bookshelf

SBS-1 Gen 2

Product description
A compact active sealed monitor: a 5.5-inch coaxial driver with a 1-inch silk dome plus a dedicated 5.5-inch midbass, driven by 350 W of Hypex nCore Class D with DSP. It reaches 26 Hz on its own and 114 dB, with full balanced, digital and analogue input options; Sigberg intends it as the core of a compact full-range system paired with dedicated subwoofers.

Performance — where it sits in the catalog

BassTrebleCone area
Bass reachTreble reachCone area
SBS-1 Gen 226 Hz20 kHz313 cm²
Median45 Hz23 kHz154 cm²
How to read this chart

Each axis spans the range the 485 bookshelves in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 98 active bookshelves — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe. Not shown: Sensitivity, Easy load — the maker publishes no figure. Active speakers quote no sensitivity and no impedance, because with the amplifier inside both describe the electronics rather than the cabinet.

Units
TypeBookshelf
HiFi ladder position#350 of 485 bookshelf
PowerActive
Height410 mm
Width190 mm
Depth230 mm
Footprint437 cm²
Space taken17.9 L
Weight9.5 kg
EnclosureSealed
Drivers1× 25 mm tweeter (silk dome), 1× 140 mm midrange (coaxial cone), 1× 140 mm mid-bass (cone)
Frequency response26–20000 Hz (±2.5 dB)
MAP (USD)$16,800 / pair
Amplification (per driver)—
Total amp power350 W
Max SPL @ 1 m114 dB
Hi-res audio—
Wired inputsRCA, XLR balanced, Optical (Toslink), Coaxial S/PDIF, AES/EBU (XLR)
Streaming / wireless—
Outputs—
Room correctionCustom DSP / app
Primary + secondary pair—
Wireless inter-speaker link—
Latency—
Idle power—
Max consumption—
Where to buyCheck availability ↗
Manufacturersigbergaudio.com ↗
Product pageOpen product page ↗
