Grand Evolution One

Product description
The flagship Evolution floorstander — a larger CST coaxial driver with a 35 mm beryllium tweeter inside a 140 mm magnesium midrange, over twin 180 mm aramid woofers, down-ported to 27 Hz and reaching 100 kHz. The closest the Evolution line comes to the Reference models, hand-assembled in Japan for a large room.

Performance — where it sits in the catalog

BassTrebleSensitivityEasy loadCone area
Bass reachTreble reachSensitivityEasy loadCone area
Grand Evolution One27 Hz100 kHz88 dB4 Ω672 cm²
Median32 Hz30 kHz90 dB6 Ω654 cm²
How to read this chart

Each axis spans the range the 648 floorstanders in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 600 passive floorstanders — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe.

Units
TypeFloorstander
HiFi ladder position#465 of 648 floorstander
PowerPassive
Height1212 mm
Width394 mm
Depth547 mm
Footprint2155 cm²
Space taken261.2 L
Weight64 kg
EnclosureBass reflex, down-firing port
Drivers2× 180 mm woofer (aramid), 1× 140 mm midrange (magnesium), 1× 35 mm tweeter (beryllium)
Crossover frequency250 / 1800 Hz
Frequency response27–100000 Hz
Sensitivity88 dB
Impedance4 Ω
Power handling250 W
MAP (USD)$65,000 / pair
Where to buyCheck availability ↗
Manufacturertechnicalaudiodevices.com ↗
Product pageOpen product page ↗
