Micro Evolution One

Product description
The compact TAD — a three-way stand-mount built around the CST coaxial driver, where a 25 mm beryllium tweeter sits at the centre of a 90 mm magnesium midrange, with a 160 mm aramid woofer. The coaxial point source is TAD's signature, and this is its most affordable expression, hand-assembled in Japan.

Performance — where it sits in the catalog

BassTrebleSensitivityEasy loadCone area
Bass reachTreble reachSensitivityEasy loadCone area
Micro Evolution One36 Hz60 kHz85 dB4 Ω270 cm²
Median45 Hz25 kHz87 dB6 Ω219 cm²
How to read this chart

Each axis spans the range the 470 bookshelves in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 385 passive bookshelves — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe.

Units
TypeBookshelf
HiFi ladder position#336 of 470 bookshelf
PowerPassive
Height411 mm
Width251 mm
Depth402 mm
Footprint1009 cm²
Space taken41.5 L
Weight20 kg
EnclosureBass reflex, rear port
Drivers1× 160 mm woofer (aramid), 1× 90 mm midrange (magnesium), 1× 25 mm tweeter (beryllium)
Frequency response36–60000 Hz
Sensitivity85 dB
Impedance4 Ω
Power handling150 W
MAP (USD)$12,495 / pair
Where to buyCheck availability ↗
Manufacturertechnicalaudiodevices.com ↗
Product pageOpen product page ↗
