TAD · Reference · Floorstander

Reference One TX

$160,000 / pairCheck availability ↗
Product description
TAD's statement floorstander — the CST coaxial driver with a 35 mm beryllium tweeter inside a 160 mm beryllium midrange, over twin 250 mm aramid woofers, reaching 21 Hz and 100 kHz at a high 90 dB sensitivity. A cost-no-object reference hand-assembled in Japan for a large dedicated room.

Performance — where it sits in the catalog

BassTrebleSensitivityEasy loadCone area
Bass reachTreble reachSensitivityEasy loadCone area
Reference One TX21 Hz100 kHz90 dB4 Ω1192 cm²
Median32 Hz30 kHz90 dB6 Ω654 cm²
How to read this chart

Each axis spans the range the 648 floorstanders in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 600 passive floorstanders — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe.

Units
TypeFloorstander
HiFi ladder position#528 of 648 floorstander
PowerPassive
Height1293 mm
Width554 mm
Depth698 mm
Footprint3867 cm²
Space taken500 L
Weight150 kg
EnclosureBass reflex, rear port
Drivers2× 250 mm woofer (aramid), 1× 160 mm midrange (beryllium), 1× 35 mm tweeter (beryllium)
Crossover frequency250 / 2000 Hz
Frequency response21–100000 Hz
Sensitivity90 dB
Impedance4 Ω
Power handling300 W
MAP (USD)$160,000 / pair
Where to buyCheck availability ↗
Manufacturertechnicalaudiodevices.com ↗
Product pageOpen product page ↗
