Tannoy · Legacy · Bookshelf
Eaton
Product description
A 254 mm Dual Concentric in a 538 mm standmount — a bookshelf only by Tannoy's reckoning, since it needs a stand, 20 kg of support and room to breathe. The reward is 40 Hz from a box this size and the same single-point radiation as the floorstanders, with front ports that tolerate a wall behind. The 33 mm dome crosses at 1.2 kHz.
Units
| Type | Bookshelf |
|---|---|
| HiFi ladder position | #320 of 367 bookshelf |
| Power | Passive |
| Height | 538 mm |
| Width | 376 mm |
| Depth | 250 mm |
| Weight | 20 kg |
| Enclosure | bass-reflex-front |
| Drivers | 1× 33 mm tweeter (aluminium/magnesium alloy dome), 1× 254 mm woofer (treated paper pulp cone with twin roll impregnated fabric surround) |
| Crossover frequency | 1200 Hz |
| Frequency response | 40–30000 Hz (±6 dB) |
| Sensitivity | 89 dB |
| Impedance | 8 Ω |
| Power handling | 100–400 W |
| Recommended amp | 20–200 W |
