Wharfedale · Diamond 12i · Bookshelf
Diamond 12.0i
TrueScaleLine this speaker up next to another at its real-world size.TrueSpecsPut this speaker's full spec sheet beside up to three others.HiFi LadderJump to this speaker's spot on the HiFi Ladder, ranked by size.
Product description
The smallest Diamond 12i: a compact 2-way standmount pairing a 25 mm woven-polyester dome tweeter with a 100 mm polypropylene mid-bass, rear-ported. The 12i refresh retunes the port for cleaner low-frequency control. 70 Hz–20 kHz, 87 dB, 8-ohm.
Suggested TrueScale comparisons
Tap any speaker to see it beside this one at true, real-world scale.
Units
| Type | Bookshelf |
|---|---|
| HiFi ladder position | #23 of 255 bookshelf |
| Power | Passive |
| Height | 265 mm |
| Width | 160 mm |
| Depth | 228 mm |
| Weight | 5.1 kg |
| Enclosure | bass-reflex-rear |
| Drivers | 1× 25 mm tweeter (woven polyester dome), 1× 100 mm mid-bass (polypropylene cone) |
| Crossover frequency | 2700 Hz |
| Frequency response | 70–20000 Hz (±3 dB) |
| Sensitivity | 87 dB |
| Impedance | 8 Ω (min 4 Ω) |
| Recommended amp | 20–60 W |
| MAP (USD) | $399 / pair |
| Where to buy | Check availability ↗ |
| Manufacturer | wharfedale.co.uk ↗ |
| Product page | Open product page ↗ |
