Wharfedale · Diamond 12i · Bookshelf
Diamond 12.2i
TrueScaleLine this speaker up next to another at its real-world size.TrueSpecsPut this speaker's full spec sheet beside up to three others.HiFi LadderJump to this speaker's spot on the HiFi Ladder, ranked by size.
Product description
The largest Diamond 12i standmount: a 2-way with a 25 mm woven-polyester dome tweeter and a 150 mm mica-loaded polypropylene mid-bass, rear-ported. Its bigger cone reaches down to 50 Hz. 88 dB, 8-ohm.
Suggested TrueScale comparisons
Tap any speaker to see it beside this one at true, real-world scale.
Units
| Type | Bookshelf |
|---|---|
| HiFi ladder position | #96 of 255 bookshelf |
| Power | Passive |
| Height | 335 mm |
| Width | 200 mm |
| Depth | 313 mm |
| Weight | 8.2 kg |
| Enclosure | bass-reflex-rear |
| Drivers | 1× 25 mm tweeter (woven polyester dome), 1× 150 mm mid-bass (mica-loaded polypropylene cone) |
| Crossover frequency | 2000 Hz |
| Frequency response | 50–20000 Hz (±3 dB) |
| Sensitivity | 88 dB |
| Impedance | 8 Ω (min 4 Ω) |
| Recommended amp | 20–120 W |
| MAP (USD) | $549 / pair |
| Where to buy | Check availability ↗ |
| Manufacturer | wharfedale.co.uk ↗ |
| Product page | Open product page ↗ |
