Yamaha · HS · Studio monitor

HS3

$195.49 / pairCheck on Amazon ↗
Product description
The smallest HS, and the first of the line sold only as a working stereo pair: the left cabinet carries the amplifier, the volume knob on its front and every input, and drives the passive right one over speaker cable. A 3.5-inch cone and 0.75-inch dome cross at 3.2 kHz for 70 Hz–22 kHz (85 Hz–20 kHz at −3 dB) and 100 dB peak, out of a cabinet 223 mm tall. Yamaha's Twisted Flare Port shapes the rear vent to cut turbulence noise. Combo XLR/TRS, RCA and stereo mini in, headphones out, plus the room control and high trim switches the series has always had. Listed dimensions are the left cabinet; the right is 12 mm shallower and 0.7 kg lighter. Also sold in white.

Performance — where it sits in the catalog

BassTrebleCone area
Bass reachTreble reachCone area
HS370 Hz22 kHz65 cm²
Median39 Hz24 kHz332 cm²
How to read this chart

Each axis spans the range the 114 studio monitors in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 96 active studio monitors — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe. Not shown: Sensitivity, Easy load — the maker publishes no figure. Active speakers quote no sensitivity and no impedance, because with the amplifier inside both describe the electronics rather than the cabinet.

Units
TypeStudio monitor
HiFi ladder position#1 of 114 studio monitor
PowerActive
Height223 mm
Width132 mm
Depth189 mm
Footprint249 cm²
Space taken5.6 L
Weight2.8 kg
EnclosureBass reflex, rear port
Drivers1× 19 mm tweeter (soft dome), 1× 89 mm woofer (cone)
Crossover frequency3200 Hz
Frequency response70–22000 Hz
MAP (USD)$195.49 / pair
Amplification (per driver)—
Total amp power26 W
Max SPL @ 1 m100 dB
Hi-res audio—
Wired inputsXLR balanced, RCA
Streaming / wireless—
Outputs—
Room correction—
Primary + secondary pairYes
Wireless inter-speaker linkNo
Latency—
Idle power—
Max consumption—
Where to buyCheck on Amazon ↗
Manufacturerusa.yamaha.com ↗
Product pageOpen product page ↗
