Yamaha · HS · Studio monitor
HS5
$169.99 eachCheck availability ↗
Product description
The white-coned monitor that became a studio default: a 5-inch cone and 1-inch dome, bi-amped with 45 W and 25 W of their own, crossing at 2 kHz for 54 Hz–30 kHz (74 Hz–24 kHz at −3 dB). Balanced XLR and TRS only — no unbalanced input, no processing — with room control and high trim switches on the back to tame a desk or a corner. Rear-ported MDF cabinet. Sold individually, in black or white. An HS5I variant adds M5 mounting points on four surfaces for brackets; it is otherwise the same speaker to the millimetre, 0.2 kg heavier.
Units
| Type | Studio monitor |
|---|---|
| HiFi ladder position | #18 of 111 studio monitor |
| Power | Active |
| Height | 285 mm |
| Width | 170 mm |
| Depth | 222 mm |
| Weight | 5.3 kg |
| Enclosure | Bass reflex, rear port |
| Drivers | 1× 25 mm tweeter (soft dome), 1× 127 mm woofer (cone) |
| Crossover frequency | 2000 Hz |
| Frequency response | 54–30000 Hz |
| MAP (USD) | $169.99 each |
| Amplification (per driver) | tweeter 25 W · woofer 45 W |
| Total amp power | 70 W |
| Max SPL @ 1 m | — |
| Hi-res audio | — |
| Wired inputs | XLR balanced |
| Streaming / wireless | — |
| Outputs | — |
| Room correction | — |
| Primary + secondary pair | No |
| Wireless inter-speaker link | No |
| Latency | — |
| Idle power | — |
| Max consumption | — |
| Where to buy | Check availability ↗ |
| Manufacturer | usa.yamaha.com ↗ |
| Product page | Open product page ↗ |
