YG Acoustics · XX · Floorstander
XX Live
$285,200 / pairCheck availability ↗
Product description
Four ways and eight drivers in the same 1.48 m cabinet as the Sonja 3 Live, which is where the extra 50 kg goes. The front carries six of them — the Lattice tweeter, two 150 mm midranges and a column of three 185 mm midbass — while the pair of 280 mm bass drivers works off the baffle, and that is the only way eight drivers fit a cabinet this size. Every one has its own 700 W amplifier, 5.6 kW a side, and the DSP crossover replaces any passive parts. 18 Hz from a sealed box.
Units
| Type | Floorstander |
|---|---|
| HiFi ladder position | #548 of 598 floorstander |
| Power | Active |
| Height | 1480 mm |
| Width | 350 mm |
| Depth | 640 mm |
| Weight | 170 kg |
| Enclosure | Sealed |
| Drivers | 1× 26 mm tweeter (Lattice hybrid dome), 2× 150 mm midrange (aluminium cone), 3× 185 mm mid-bass (aluminium cone), 2× 280 mm woofer (aluminium cone) |
| Frequency response | 18–40000 Hz |
| MAP (USD) | $285,200 / pair |
| Amplification (per driver) | tweeter 700 W · midrange 1400 W · mid-bass 2100 W · woofer 1400 W |
| Total amp power | 5600 W |
| Max SPL @ 1 m | — |
| Hi-res audio | 24 bit / 384 kHz |
| Wired inputs | AES/EBU (XLR), Coaxial S/PDIF, Optical (Toslink), USB Audio, Ethernet, RCA, RCA Phono |
| Streaming / wireless | Roon Ready |
| Outputs | — |
| Room correction | — |
| Primary + secondary pair | — |
| Wireless inter-speaker link | — |
| Latency | — |
| Idle power | — |
| Max consumption | — |
| Where to buy | Check availability ↗ |
| Manufacturer | yg-acoustics.com ↗ |
| Product page | Open product page ↗ |
