Zu Audio · Definition · Floorstander

Definition 6

Product description
Zu's flagship — two 10-inch full-range drivers in an MTM array around a ring-radiating supertweeter, run with no crossover, backed by a front-firing 12-inch powered subwoofer with an internal Hypex amplifier and adjustable tuning. The passive mains need only a few watts while the active bass reaches deep, all in an all-okoume cabinet hand-built in Ogden, Utah.

Performance — where it sits in the catalog

BassTrebleEasy load
Bass reachTreble reachEasy load
Definition 630 Hz22 kHz8 Ω
Median32 Hz30 kHz6 Ω
How to read this chart

Each axis spans the range the 648 floorstanders in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 600 passive floorstanders — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe. Not shown: Sensitivity, Cone area — the maker publishes no figure.

Units
TypeFloorstander
HiFi ladder position#564 of 648 floorstander
PowerPassive
Height1370 mm
Width330 mm
Depth330 mm
Footprint1089 cm²
Space taken149.2 L
Weight45 kg
EnclosureSealed
Drivers2× 262 mm woofer (paper/carbon-nanotube full-range cone), 1× super-tweeter (Eminence N151M ring radiator), 1× 305 mm woofer (Eminence LAB-12 cone)
Frequency response30–22000 Hz
Impedance8 Ω
MAP (USD)$27,000 / pair
Where to buyCheck availability ↗
Manufacturerzuaudio.com ↗
Product pageOpen product page ↗

Suggested TrueScale comparisons

Tap any speaker to see it beside this one at true, real-world scale.
