Adam Audio · S Series · Studio monitor
S3V
$3,400 eachCheck availability ↗
Product description
The vertical three-way midfield of ADAM's flagship S Series — a 9-inch HexaCone woofer, a 4-inch DCH carbon dome/cone midrange and the hand-built S-ART folded-ribbon tweeter, triamped with 850 W and a full DSP engine. A 25 kg mastering-grade monitor for medium-to-large control rooms, made in Berlin.
Units
| Type | Studio monitor |
|---|---|
| HiFi ladder position | #72 of 107 studio monitor |
| Power | Active |
| Height | 536 mm |
| Width | 293 mm |
| Depth | 380 mm |
| Weight | 25 kg |
| Enclosure | Bass reflex, front port |
| Drivers | 1× tweeter (S-ART folded ribbon), 1× 100 mm midrange (DCH carbon dome/cone hybrid), 1× 229 mm woofer (HexaCone) |
| Crossover frequency | 250 / 3000 Hz |
| Frequency response | 32–50000 Hz |
| MAP (USD) | $3,400 each |
| Amplification (per driver) | tweeter 50 W (class AB) · midrange 300 W (class D) · woofer 500 W (class D) |
| Total amp power | 850 W |
| Max SPL @ 1 m | 124 dB |
| Hi-res audio | — |
| Wired inputs | XLR balanced, AES/EBU (XLR) |
| Streaming / wireless | — |
| Outputs | — |
| Room correction | Custom DSP / app |
| Primary + secondary pair | — |
| Wireless inter-speaker link | — |
| Latency | — |
| Idle power | — |
| Max consumption | — |
| Where to buy | Check availability ↗ |
| Manufacturer | adam-audio.com ↗ |
| Product page | Open product page ↗ |
