Canton · Reference Alpha · Floorstander

Reference Alpha 2

Product description
The compact Reference Alpha — the same three-way topology with the DLC diamond tweeter and 174 mm BCT midrange, here over four 192 mm BCT woofers in a curved cabinet. It trades a little scale for a smaller footprint, a diamond-tweeter flagship for a large room.

Performance — where it sits in the catalog

BassTrebleSensitivityEasy loadCone area
Bass reachTreble reachSensitivityEasy loadCone area
Reference Alpha 218 Hz40 kHz89 dB4 Ω1401 cm²
Median32 Hz30 kHz90 dB6 Ω654 cm²
How to read this chart

Each axis spans the range the 648 floorstanders in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 600 passive floorstanders — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe.

Units
TypeFloorstander
HiFi ladder position#577 of 648 floorstander
PowerPassive
Height1420 mm
Width378 mm
Depth660 mm
Footprint2495 cm²
Space taken354.3 L
Weight91 kg
EnclosureBass reflex, down-firing port
Drivers1× 25 mm tweeter (DLC diamond-coated dome), 1× 174 mm midrange (Black Ceramic Tungsten cone), 4× 192 mm woofer (Black Ceramic Tungsten cone)
Crossover frequency160 / 3100 Hz
Frequency response18–40000 Hz (±3 dB)
Sensitivity89 dB
Impedance4 Ω (min 4 Ω)
Power handling500 W
MAP (USD)$50,000 / pair
Where to buyCheck availability ↗
Manufacturercanton.de ↗
Product pageOpen product page ↗
