HEDD Audio · Type · Studio monitor

Type 20 MK2

Product description
The smaller of HEDD's two horizontal three-ways: a 7-inch honeycomb woofer beside a column holding the 4-inch midrange under the Air Motion Transformer, so the mid and treble stay vertically aligned when the cabinet lies on its side — which is how it is meant to sit, and how HEDD photographs it. Because the woofer is off to one side it ships handed: you order a left or a right. Three 300 W ICEpower stages, crossovers at 250 Hz and 3.2 kHz, and a 32-bit SHARC DSP running HEDD's Lineariser zero-phase filter. A POM plug converts the ported cabinet to sealed — HEDD's CoP switch — trading bass extension for tighter transients. 120 dB per pair at 1 m. Analogue XLR and AES with pass-through. Sold individually. Made in Berlin.
Units
TypeStudio monitor
HiFi ladder position#16 of 111 studio monitor
PowerActive
Height280 mm
Width358 mm
Depth338 mm
Weight15.4 kg
EnclosureBass reflex, front port
Drivers1× tweeter (Air Motion Transformer), 1× 102 mm midrange (honeycomb sandwich cone), 1× 178 mm woofer (honeycomb sandwich cone)
Crossover frequency250 / 3200 Hz
Frequency response32–40000 Hz
MAP (USD)$2,399 each
Amplification (per driver)tweeter 300 W (class D) · midrange 300 W (class D) · woofer 300 W (class D)
Total amp power900 W
Max SPL @ 1 m120 dB
Hi-res audio32 bit / 96 kHz
Wired inputsXLR balanced, AES/EBU (XLR)
Streaming / wireless—
Outputs—
Room correctionCustom DSP / app
Primary + secondary pairNo
Wireless inter-speaker linkNo
Latency—
Idle power—
Max consumption—
