HEDD Audio · Type · Studio monitor
Type 30 MK2
$3,199 eachCheck availability ↗
Product description
HEDD's largest Type: two 7-inch honeycomb woofers flanking a central column with the 4-inch midrange under the Air Motion Transformer — symmetrical about the vertical axis when the cabinet lies down, which keeps the mid and treble on one line and is why it is filed horizontally here. Same three 300 W ICEpower stages and 250 Hz / 3.2 kHz crossovers as the Type 20, with twice the cone area behind them: 125 dB per pair at 1 m against the 20's 120. The CoP plug switches the cabinet between ported and sealed, and the SHARC DSP carries the Lineariser along with desktop and shelving filters. Analogue XLR and AES with pass-through. Sold individually. Made in Berlin.
Units
| Type | Studio monitor |
|---|---|
| HiFi ladder position | #11 of 78 studio monitor |
| Power | Active |
| Height | 280 mm |
| Width | 530 mm |
| Depth | 338 mm |
| Weight | 21.5 kg |
| Enclosure | bass-reflex-front |
| Drivers | 1× tweeter (Air Motion Transformer), 1× 102 mm midrange (honeycomb sandwich cone), 2× 178 mm woofer (honeycomb sandwich cone) |
| Crossover frequency | 250 / 3200 Hz |
| Frequency response | 32–40000 Hz |
| MAP (USD) | $3,199 each |
| Amplification (per driver) | tweeter 300 W (class D) · midrange 300 W (class D) · woofer 300 W (class D) |
| Total amp power | 900 W |
| Max SPL @ 1 m | 125 dB |
| Hi-res audio | 32 bit / 96 kHz |
| Wired inputs | XLR balanced, AES/EBU (XLR) |
| Streaming / wireless | — |
| Outputs | — |
| Room correction | Custom DSP / app |
| Primary + secondary pair | No |
| Wireless inter-speaker link | No |
| Latency | — |
| Idle power | — |
| Max consumption | — |
| Where to buy | Check availability ↗ |
| Manufacturer | hedd.audio ↗ |
| Product page | Open product page ↗ |
