Klipsch · Heritage · Floorstander

Klipschorn AK7

Product description
The latest evolution of the corner-loaded Klipschorn, in production since 1946 — the AK7 upgrades the HF and MF compression drivers over the 15-inch folded-horn woofer. With 103 dB sensitivity and an optional active DSP crossover, it remains a fully horn-loaded classic that turns room corners into its bass horn.

Performance — where it sits in the catalog

BassTrebleSensitivityEasy loadCone area
Bass reachTreble reachSensitivityEasy loadCone area
Klipschorn AK734 Hz19 kHz103 dB8 Ω1165 cm²
Median32 Hz30 kHz90 dB6 Ω654 cm²
How to read this chart

Each axis spans the range the 648 floorstanders in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 600 passive floorstanders — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe.

Units
TypeFloorstander
HiFi ladder position#556 of 648 floorstander
PowerPassive
Height1352 mm
Width801 mm
Depth715 mm
Footprint5727 cm²
Space taken774.3 L
Weight118 kg
Enclosure—
Drivers1× 25 mm tweeter (K-771 compression diaphragm), 1× 51 mm midrange (K-933-HP compression diaphragm), 1× 381 mm woofer (K-33-E fiber-composite cone)
Crossover frequency380 / 2900 Hz
Frequency response34–19000 Hz (±4 dB)
Sensitivity103 dB
Impedance8 Ω (min 4 Ω)
Power handling300 W
MAP (USD)$19,998 / pair
