Neumann · KH Line · Studio monitor
KH 80 DSP
$599 eachCheck availability ↗
Product description
Neumann's smallest monitor and its first with DSP: a 4-inch composite woofer and 1-inch alloy dome in a 233 mm cabinet, bi-amplified to 190 W with a linear-phase crossover at 1.8 kHz. The network port is not for audio — it carries the MA 1 alignment system, which measures the room with a supplied microphone and writes the correction into the monitor itself. Sold individually; also offered in white. Made in Germany.
Units
| Type | Studio monitor |
|---|---|
| HiFi ladder position | #2 of 111 studio monitor |
| Power | Active |
| Height | 233 mm |
| Width | 154 mm |
| Depth | 194 mm |
| Weight | 3.5 kg |
| Enclosure | Bass reflex, front port |
| Drivers | 1× 25 mm tweeter (alloy fabric dome), 1× 100 mm woofer (composite sandwich cone) |
| Crossover frequency | 1800 Hz |
| Frequency response | 57–21000 Hz (±3 dB) |
| MAP (USD) | $599 each |
| Amplification (per driver) | tweeter 70 W (class D) · woofer 120 W (class D) |
| Total amp power | 190 W |
| Max SPL @ 1 m | 109 dB |
| Hi-res audio | — |
| Wired inputs | XLR balanced, Ethernet |
| Streaming / wireless | — |
| Outputs | — |
| Room correction | Custom DSP / app |
| Primary + secondary pair | No |
| Wireless inter-speaker link | No |
| Latency | — |
| Idle power | — |
| Max consumption | — |
| Where to buy | Check availability ↗ |
| Manufacturer | neumann.com ↗ |
| Product page | Open product page ↗ |
